The High Power Wall Washer lighting Series

is one of the R+K product lines that emphasize projection and performance in architectural lighting applications. This series of products has the characteristics of high luminous flux, narrow beam angle and long-distance light projection, are able to accept external signals from DMX and SDC to perform scheduled lighting shows.The luminaire is IP68 rated (dust and waterproof sealed), the adjustable base bracket aids fitting in many different installations. The High power series are suitable for highlighting architectural features, as well as creating dramatic lighting effects on such as bridge stage scenery .

HP Spot Light (RGB)

Applications:
Area: Outdoor
Purpose: Architectural lighting, accent lighting, site lighting

Features:
– Aluminum die-casting alloy housing
– High performance IP-free LED, top-tier suppliers
– Selectable optics, 10°, 30°, 10°x30°
– Control signal, DMX and SDC
– Easy addressing specially for SDC technology
– IP68 ingress protection rating
– Safety certification: CE

HP Spot Light (White)

Applications:
Area: Outdoor
Purpose: Accent lighting, site lighting, architecture lighting

Features:
–High performance IP-free LED, top-tier suppliers
–High luminaire efficacy (100 lm/W for 5200K)
–High color rendering index, CRI 70 for 4000K/5200K and CRI 80 for 3000K
–Available in 3000K/4000K/5200K color temperatures
–Selectable optics, 10°, 30°and 10°x30°
–Rugged die-cast aluminum housing and stainless mounting bracket in silver baked painting
–Tempered glass, impact-resistant
–IP68 ingress protection rating, suitable for outdoor applications
–Long operating life, over 40,000 hours
–Hazard-free materials
–Safety certifications: CE, PSE

HP Flood Light (RGB) Applications:
Area: Outdoor
Purpose: Architectural lighting, accent lighting, site lighting

Features:
– Aluminum die-casting alloy housing
– High performance IP-free LED, top-tier suppliers
– Selectable optics, 10°, 30°, 10°x30°
– Control signal, DMX and SDC
– Easy addressing specially for SDC technology
– IP68 ingress protection rating
– Safety certification: CE

HP Flood light (White) Applications:
Area: Outdoor
Purpose: Accent lighting, site lighting, architecture lighting

Features:
–High performance IP-free LED, top-tier suppliers
–High luminaire efficacy (102 lm/W for 5200K)
–High color rendering index, CRI 70 for 4000K/5200K and CRI 80 for 3000K
–Available in 3000K/4000K/5200K color temperatures
–Selectable optics, 10°, 30°and 10°x30°
–Rugged die-cast aluminum housing and stainless mounting bracket in silver baked painting
–Tempered glass, impact-resistant
–IP68 ingress protection rating, suitable for outdoor applications
–Long operating life, over 40,000 hours
–Hazard-free materials
–Safety certifications: CE, PSE

HP Linear Light (RGB)

Applications:
Area: Outdoor
Purpose: Accent lighting, site lighting, architecture lighting

HP Linear Light (White)

Applications:
Area: Outdoor
Purpose: Accent lighting, site lighting, architecture lighting

Features:
–High performance IP-free LED, top-tier suppliers
–High luminaire efficacy (102 lm/W for 5200K)
–High color rendering index, CRI 70 for 4000K/5200K and CRI 80 for 3000K
–Available in 3000K/4000K/5200K color temperatures
–Selectable optics, 10°, 30°and 10°x30°
–Aluminum alloy housing with anodized treatment and stainless mounting bracket
–Tempered glass, impact-resistant
–IP68 ingress protection rating, suitable for outdoor applications
–Long operating life, over 40,000 hours
–Hazard-free materials
–Safety certifications: CE

HP Linear Light (White) Applications:
Area: Outdoor
Purpose: Accent lighting, site lighting, architecture lighting

Features:
–High performance IP-free LED, top-tier suppliers
–High luminaire efficacy (102 lm/W for 5200K)
–High color rendering index, CRI 70 for 4000K/5200K and CRI 80 for 3000K
–Available in 3000K/4000K/5200K color temperatures
–Selectable optics, 10°, 30°and 10°x30°
–Aluminum alloy housing with anodized treatment and stainless mounting bracket
–Tempered glass, impact-resistant
–IP68 ingress protection rating, suitable for outdoor applications
–Long operating life, over 40,000 hours
–Hazard-free materials
–Safety certifications: CE

HP Mini Spot Light (RGB) Area: Outdoor
Purpose: Accent lighting, site lighting, architecture lighting.

HP Mini Spot Light (White) Area: Outdoor
Purpose: Accent lighting, site lighting, architecture lighting.

AGLAIA-18DCF Flood Light (RGB)

Applications:
Area: Outdoor
Purpose: Architectural lighting, accent lighting, site lighting

Features:
– Aluminum die-casting alloy housing
– High performance IP-free LED, top-tier suppliers
– Selectable optics, 10°, 30°, 10°x30°
– Control signal, DMX and SDC
– Easy addressing specially for SDC technology
– IP68 ingress protection rating
– Safety certification: CE

AGLAIA-18ACF 125W Flood Light (RGB)

Applications
Outdoor color-changing flood light designed with narrow-beam and full-color light projection

capability for architecture, bridge and site lighting application.

Features
– Versatile optics: 10°/ 30° beam angle support a multitude of applications and features precise aiming capabilities.
– Control options: DMX/SDC and stand-alone.
– Universal power input range: Integral power supply for 100-240Vac input.
– Simple mounting fixture positioning and fixture rotation capability through side locking bolts.
– LED modules driving by low-voltage DC without safety risk.
– Switching mode and multi-channel constant current design.
– High power factor design(>0.9).
– IP65 ingress protection.
– Long life and save maintenance cost.

AGLAIA-18ACF 250W Flood Light (RGB)

Applications:
Area: Outdoor
Purpose: Architectural lighting, project lighting

Features:
–Versatile optics: 10°/ 30°/10°x30° beam angle

support a multitude of applications and features precise aiming capabilities.
–Control options: DMX/SDC and stand-alone.
–Universal power input range: Integral power supply for 100-240Vac input.
–Simple mounting fixture positioning and fixture rotation capability through side locking bolts.
–LED modules driving by low-voltage DC without safety risk.
–Switching mode and multi-channel constant current design.
–High power factor design(>0.9).
–IP65 ingress protection.
–Long life and save maintenance cost.

Applicable Controller





EZ-DD EZ-DD is a high speed data distributor for EZ-10K control system. It features with maximum 30 frame rate and is capable of supporting maximum 200 pixels SDC lighting fixtures.

Features?
–High speed data distributor up to 30 frame rate.
–Allowable to support maximum 200 pixels SDC lighting fixtures.
–Start pixel easily adjustable via digital display and tact switch.
–Support cat5e cable for connecting EZ-10K and EZ-DD.

EZ Launcher is an address setting control system which can collocate with AOP wall washers. User can select address by self-use signal type. EZ Launcher provides a user friendly solution with its small volume and easy operation system.

- Maximum Value: 520
- Address setting easily
- Compact size and light-weighted
- User friendly operation system

EZ-DD4 provides more portals for the DMX isolator system; 1 for input, 4 for output. Each input-output set is equipped with its isolation power and signal to protect both DMX controllers and lights. The product provides DMX a worth trusting system to avoid bugs of controllers or lights.

EZ-Transfer Features:
- DMX to SDC interface
- Allow maximum 170 pixels to be controlled
- Intelligent addressing by setting the first DMX address only.
- Can be used as Signal Amplifier / Repeater
- Signal & power LED indicators for status monitoring.

DP-1000 DALI to PWM Converter Application:
Enable LED luminaires with PWM dimming interface to be controlled by DALI system
Features:
–Convert DALI control signal into PWM signal
–PWM signal can be switched to 5V or 10V output level
–2 PWM Output ports
